Knightsbridge SN2000 10AX 1G 2-Way Switch – White Square Edge

The Knightsbridge SN2000 is a white, square-edge, single-gang two-way light switch rated at 10AX. It is supplied with screw-cap covers for a tidy finish.

• Manufacturer model: SN2000
• EAN: 5055832953180
• Switching: 1 gang, 2 way
• Rating: 10AX, 230V, 50Hz
• Material: white thermoset resin
• Protection: IP20, for indoor use
• Plate size: 86 mm high × 86 mm wide
• Overall depth: 23 mm, including 13.1 mm projection and 9.9 mm recessed depth, as listed in the current manufacturer datasheet
• Minimum mounting-box depth: 16 mm; select a suitable box for the actual wiring
• Terminal capacity: 2 × 1.0 mm² or 2 × 1.5 mm²

Two-way switching allows a lighting circuit to be controlled from two positions when correctly wired with another suitable two-way switch. Follow the manufacturer's diagram for the intended circuit.

Manufacturer drawing

Open the original manufacturer drawing at full size

Manufacturer documents

• SN2000 manufacturer datasheet (PDF)
• Manufacturer wiring-accessory installation and wiring diagrams (PDF)

The instruction sheet covers several wiring accessories. Use the two-way-switch section and check the terminal markings on the actual product, as terminal positions may vary. Isolate the supply before work and use a qualified electrician where required.
