Knightsbridge SN127 10AX 1G 2-Way Architrave Switch – White

The Knightsbridge SN127 is a narrow 1-gang, 2-way architrave switch with a white Square Edge plate. Its 32mm width suits locations where a standard-width switch plate will not fit.

Product details

• Manufacturer model: SN127
• Rating: 10AX; supply: 230V 50Hz
• Configuration: 1-gang, 2-way
• Plate size: 86mm high × 32mm wide
• Overall depth: 23mm; total projection: 13.1mm; recessed depth: 9.9mm
• Minimum mounting depth: 16mm
• Construction: white thermoset resin
• IP20; no earth terminal on the switch
• Terminal capacity: 2 × 1.0mm² or 2 × 1.5mm²
• Includes screw cap covers
• Manufacturer-stated standard: BS EN 60669-1

The matching SN127P architrave pattress box is a separate accessory.

Manufacturer drawing

The drawing shows the 9mm plate and 4.1mm rocker projection, giving the 13.1mm total projection in the datasheet. Check the drawing and mounting space before fitting.

Manufacturer documents

• SN127 manufacturer datasheet (PDF)
• Manufacturer-linked wiring-accessory instructions (PDF, DCJUN22)

The manufacturer links this general wiring-accessory sheet for SN127. Use its 2-way switch section and the actual unit's terminal markings; terminal positions may vary. Read the full instructions and isolate the supply before installation.
