Knightsbridge SN3000 10AX 2G 2-Way Switch – White Square Edge

The Knightsbridge SN3000 is a white Square Edge two-gang, two-way light switch rated at 10AX. It has two separate rockers and includes screw-cap covers.

• Model: SN3000
• Switch function: 2-gang, 2-way
• Rating: 10AX, 230 V, 50 Hz
• Dimensions: 86 mm high × 86 mm wide; 23 mm overall depth
• Projection / recessed depth: 13.1 mm / 9.9 mm
• Plate depth: 9 mm; the rocker adds 4.1 mm to the projection shown in the drawing
• Minimum mounting-box depth: 16 mm
• Construction: white thermoset resin
• Terminal capacity: 2 × 1.0 mm² or 2 × 1.5 mm²
• Earth terminal on the accessory: none
• Protection: IP20, indoor use
• Manufacturer-listed standard: BS EN 60669-1
• EAN: 5055832953241

Two-way lighting control requires a suitable circuit and a corresponding switch at the other control point. Check the installation and circuit suitability against the manufacturer instructions.

Manufacturer dimensions

View the full-size SN3000 manufacturer drawing

Manufacturer documents

• SN3000 manufacturer datasheet (PDF)
• Manufacturer wiring-accessories instructions — DCJUN22 (PDF)

The current datasheet lists a 25-year manufacturer warranty, subject to the manufacturer's applicable installation and use terms.
