Knightsbridge SN7000 13A 1G DP Switched Socket – White Square Edge

The Knightsbridge SN7000 is a white Square Edge one-gang 13A double-pole switched socket. It has a 9 mm plate and includes screw-cap covers.

• Model: SN7000
• Configuration: 1-gang switched socket, double-pole switch
• Rating: 13A, 230 V, 50 Hz
• Dimensions: 86 mm high × 86 mm wide; 31.6 mm overall depth
• Total projection / recessed depth: 13.7 mm / 17.9 mm
• Plate depth: 9 mm; the rocker adds 4.7 mm to the projection shown in the drawing
• Minimum mounting-box depth: 25 mm
• Construction: white thermoset resin
• Earth terminal: yes
• Terminal capacity: 3 × 2.5 mm² or 2 × 4.0 mm²
• Protection: IP20, indoor use
• Manufacturer-listed standard: BS 1363-2
• EAN: 5055832952916

The manufacturer describes this exact model as ASTA approved under licence 1412 and states that its anti-microbial properties were third-party tested to ISO 22196:2011. Follow the manufacturer instructions and check the circuit, earthing and available wiring space before fitting.

Manufacturer dimensions

View the full-size SN7000 manufacturer drawing

Manufacturer documents

• SN7000 manufacturer datasheet (PDF)
• Manufacturer wiring-accessories instructions — DCJUN22 (PDF)

The current datasheet lists a 25-year manufacturer warranty, subject to the manufacturer's applicable installation and use terms.
