Knightsbridge SN9001 13A 2G DP Socket – Outboard Rockers, White
Original price
£4.50
-
Original price
£4.50
Original price
£4.50
£4.50
-
£4.50
Current price
£4.50
The Knightsbridge SN9001 is a white Square Edge 13A two-gang double-pole switched socket with outboard rockers and twin earth terminals. It has top-access captive terminals and screw-cap covers.
- Model: SN9001
- Rating: 13A, 230 V, 50 Hz
- Switching: double pole, outboard rockers
- Construction: white thermoset resin
- Dimensions: 86 mm high × 146 mm wide; 31.2 mm overall depth
- Total projection / recessed depth: 13.1 mm / 18.1 mm
- Plate depth: 9 mm; the rockers add 4.1 mm to the projection shown in the drawing
- Minimum mounting-box depth: 25 mm
- Terminal capacity: 3 × 2.5 mm² or 2 × 4.0 mm²
- Protection: IP20, indoor use
- Manufacturer-listed standard: BS 1363-2
- EAN: 5056270823189
Check the mounting box, wiring space and installation conditions before fitting. Installation must follow the manufacturer instructions; verify that the supply is isolated before work.
Manufacturer dimensions
View the full-size SN9001 manufacturer drawing
Manufacturer documents
The current datasheet lists a 25-year manufacturer warranty, subject to the manufacturer's applicable installation and use terms.
