Knightsbridge FP5ABCW 5A Round-Pin Socket – Brushed Chrome/White

The Knightsbridge FP5ABCW is a 5A unswitched round-pin socket from the Flat Plate range, with a brushed-chrome faceplate, white inserts and visible screw fixings. The manufacturer describes it for custom lighting solutions.

Product details

• Manufacturer model: FP5ABCW
• Rating: 5A; supply: 230V 50Hz
• Unswitched 5A round-pin socket
• Construction: 201 stainless steel; brushed-chrome finish with white inserts
• Low-profile flat plate with built-in gasket
• Plate dimensions: 87.5mm high × 87.5mm wide
• Overall depth: 23.6mm; projection: 2.5mm; recessed depth: 21.1mm
• Fixing centres: 60.3mm
• Minimum mounting box depth: 25mm
• Earth terminal provided
• Terminal capacity: 2 × 1.0mm² or 2 × 1.5mm²
• IP20; indoor use only
• Manufacturer-stated standard: BS 546

Manufacturer drawing

The manufacturer links this FP5Axx family drawing for FP5ABCW; it shows the front, side and rear views.

Manufacturer documents

• FP5ABCW manufacturer datasheet (PDF)
• Manufacturer wiring-accessories instructions (PDF)

The manufacturer links this general wiring-accessories instruction sheet for FP5ABCW; refer to its 5A unswitched round-pin socket section. Read the full instructions, check the actual unit's terminal markings and isolate the supply before installation.
