Knightsbridge FP6300NPC 13A Fused Spur with Neon – Polished Chrome

The Knightsbridge FP6300NPC is a polished-chrome FlatPlate 13A switched fused connection unit with a neon indicator. It has double-pole switching, matching fuse-holder and rocker finishes, visible fixing screws and a built-in gasket.

• Model: FP6300NPC
• Unit rating: 13A, 230 V, 50 Hz
• Switching: double pole
• Construction: 201 stainless steel
• Finish: polished chrome
• Dimensions: 87.5 mm high × 87.5 mm wide; 27.6 mm overall depth
• Total projection / recessed depth: 7.4 mm / 20.2 mm
• Plate thickness: 2.5 mm; the rocker adds 4.9 mm to the projection shown in the drawing
• Minimum mounting-box depth: 25 mm
• Earth terminal: yes
• Terminal capacity: 3 × 2.5 mm² or 2 × 4.0 mm²
• Protection: IP20, indoor use
• Manufacturer-listed standard: BS 1363-4
• EAN: 5055832918134

Fuse selection: 13A is the unit rating. The fuse fitted to the supplied unit has not been physically checked; select and verify the fuse rating to suit the appliance, cable and circuit. Check the mounting box and wiring space before installation, follow the manufacturer instructions and verify that the supply is isolated before work.

Manufacturer dimensions

View the full-size manufacturer drawing for FP6300NPC

Manufacturer documents

• FP6300NPC manufacturer datasheet (PDF)
• Manufacturer wiring-accessories instructions — DCAUG22 V3 (PDF)

The current datasheet lists a 25-year manufacturer warranty, subject to the manufacturer's applicable installation and use terms.
