Knightsbridge FPR9000BCW 13A 2G DP Socket – Brushed Chrome / White

Original price £14.18 - Original price £14.18
Original price
£14.18
£14.18 - £14.18
Current price £14.18

The Knightsbridge FPR9000BCW is a FlatPlate two-gang 13A switched socket in brushed chrome with white inserts and matching metal rockers. It has double-pole switches, twin earth terminals and a built-in gasket.

  • Model: FPR9000BCW
  • Configuration: 2-gang switched socket, double-pole switches
  • Rating: 13A, 230 V, 50 Hz
  • Current datasheet dimensions: 87.5 mm high × 147.5 mm wide; 30.9 mm overall depth
  • Projection / recessed depth: 7.7 mm / 23.2 mm
  • Minimum mounting-box depth: 25 mm
  • Construction: 201 stainless steel, brushed-chrome finish and white socket inserts
  • Earth connections: twin earth terminals
  • Terminal capacity: 3 × 2.5 mm² or 2 × 4.0 mm²
  • Protection: IP20, indoor use
  • Manufacturer-listed standard: BS 1363-2
  • EAN: 5055832958031

Dimension check: the current exact-model datasheet lists 147.5 mm width, while the manufacturer-linked drawing below shows 148.5 mm. Both show 87.5 mm height and 30.9 mm overall depth. Actual supplied-unit width and installation fit remain unverified; check the unit and available space before fitting.

Follow the manufacturer instructions and check the installation's earthing and circuit suitability. IP20 is an indoor rating; the built-in gasket does not make the socket waterproof.

Manufacturer dimensions

FPR9000BCW manufacturer-linked original dimensional drawing showing148.5mm width

View the original full-size manufacturer drawing

Manufacturer documents
