Wiska Shark 506W Gel Insulated Cable Joint (SH506W) UK

The Wiska Shark 506W is a pre-filled gel insulated cable joint with terminal block and strain relief system. Made in Italy by Etelec, this professional-grade joint provides reliable waterproof insulation for cable connections rated at 0.6/1kV.

The silicone gel filling creates an effective barrier against dirt and water ingress. Reusable — the gel can be resealed without the need to refill, making it ideal for both permanent and temporary installations.

Features:

• Pre-filled gel insulated straight joint
• 5-pole terminal block with Allen key mechanical connectors
• Cable strain relief system
• Armour/shield bond kit with constant force roll springs and earth braid
• Reusable gel seal — no refilling needed
• IP68 rated waterproof protection

Specifications:

• Model: Shark 506W (SH0506W)
• Voltage Rating: 0.6/1kV
• Current Rating: 80A
• Cable Size: 3-5 core, 1.5-6mm²
• Single Cable: 1 x 95-240mm²
• Compatible: PVC, XLPE, EPR, Normal, Armoured or Shielded cables
• Dimensions: 180 x 69 x 40mm
• Made in Italy
• Manufacturer: Etelec / Wiska
• Barcode: 8033712906393
