Domestic Air Conditioning: Split Systems, Multi-Split, Cassette Units, and F-Gas Rules for UK Trades

Demand for residential air conditioning has accelerated sharply since the 2022 and 2023 heat events, and UK installers now face a wider product range, stricter refrigerant rules, and customers who are more cost-aware than ever. This guide covers the main system types available for domestic properties, the refrigerant landscape post-F-Gas Phase-Down, wiring and Part P requirements, and the commissioning steps that keep warranty and compliance intact.

Why Domestic AC Is Growing in the UK

The UK has historically lagged European neighbours in residential AC penetration. That gap is closing fast. Mean summer temperatures are rising, heat pumps are normalising mechanical refrigeration in homes, and planning rules in England now allow permitted development for wall-mounted split system outdoor units on most dwellings (subject to size limits and listed-building restrictions). Contractors who can design, supply, and install a compliant domestic AC system are capturing margin that previously went to specialist firms.

System Types

Wall-Mounted Split System

The most common domestic choice. A single outdoor condenser/compressor unit connects to one indoor evaporator (fan coil) via refrigerant lines and a control cable. Cooling capacities run from 2 kW to 7 kW — matching the majority of UK rooms (living rooms, bedrooms, home offices). Most modern inverter-driven split systems can also reverse cycle for heating, making them year-round appliances rather than seasonal luxuries.

Key specification factors:

• Cooling capacity (kW): Calculate from room volume, glazing, orientation, and occupancy. A rule of thumb is 80–125 W/m² for well-insulated UK rooms; conservatories and south-facing glazed rooms can exceed 250 W/m².
• SEER/SCOP rating: ErP Directive compliance. Look for A++ or A+++ rated units; these attract higher consumer interest and carry lower running costs.
• Refrigerant: R32 is now the dominant domestic refrigerant, replacing R410A. R32 has lower GWP (675 vs 2,088) and improved efficiency but is mildly flammable (A2L). Installer training and safe-handling rules apply — see F-Gas section below.
• Pipe run: Maximum refrigerant pipe length and height differential vary by manufacturer — typically 20–25 m total length, 10–15 m height difference. Exceeding these without refrigerant top-up voids commissioning.
• Noise: Outdoor unit dB(A) ratings matter in urban gardens and terraced properties. Sub-50 dB(A) at 1 m is reasonable; some premium units hit 43–46 dB(A).

Multi-Split System

One outdoor unit (usually 5–14 kW) feeds multiple indoor units across different rooms. Each indoor unit has independent temperature control. Total indoor capacity must not exceed outdoor unit capacity by more than the manufacturer's expansion ratio (typically 30–50%). Multi-split suits two- to four-room installations where running separate outdoor units is impractical — semi-detached properties with limited wall space, or upper-floor bedrooms served from a single condenser.

Refrigerant charge is higher and pipe runs more complex, so F-Gas record-keeping is especially important. Always check that the outdoor unit can handle the combination of indoor units chosen — manufacturers publish compatibility matrices.

Cassette Unit

Ceiling-recessed unit with 360° or 2-way airflow distribution. Suited to open-plan ground floors, kitchen-diners, and extensions where wall mounting is aesthetically undesirable. Requires a false ceiling or ceiling void ≥ 250 mm deep. Installation involves structural fixings to ceiling joists, a condensate drain line (often pump-assisted), and careful coordination with decorators. Not typically a DIY retrofit — cassette installs are usually planned at fit-out stage.

Portable and Window Units

No refrigerant work required; these are plug-in self-contained units. Cooling efficiency is significantly lower than split systems, and hot air must be ducted outside via a flexible hose (window or through-wall). These are outside the F-Gas Regulation scope as sealed pre-charged units. Useful for temporary or rental situations but not a premium trade installation product.

F-Gas Regulation and Refrigerant Rules

The UK retained and updated the EU F-Gas Regulation after Brexit. The current UK F-Gas Regulation (retained EU 517/2014, as amended) applies to all stationary refrigeration, air conditioning, and heat pump equipment containing fluorinated greenhouse gases (F-gases).

Certification Requirements

Anyone who handles F-gas refrigerants — including installing, commissioning, servicing, decommissioning, or recovering refrigerant — must hold an F-Gas Category I or Category II certificate (or equivalent) issued by an approved body (Refcom, CITB, City & Guilds, etc.). Uncertified persons may not purchase, handle, or work with refrigerants.

R32 is classified A2L (mildly flammable). Additional safe-handling requirements include:

• Use of A2L-rated manifold gauges, hoses, and recovery equipment
• No ignition sources within 3 m during handling
• Adequate ventilation in enclosed spaces
• Refrigerant recovery before any work on refrigerant circuit

F-Gas Record-Keeping

For systems containing ≥ 3 kg CO₂ equivalent of F-gas (about 0.9 kg of R32, or 0.43 kg of R410A), you must:

• Maintain an equipment log recording refrigerant type, charge, installation date, service history, and quantities added/removed
• Carry out regular leak checks (annual for ≥ 3 kg CO₂ eq, quarterly for ≥ 30 kg CO₂ eq)
• Submit reports to the UK F-Gas Registry where required

Most domestic single splits with 0.6–1.0 kg R32 charges fall below the 3 kg CO₂ eq threshold (~2 kg CO₂ eq for 0.9 kg R32) — no mandatory leak checks, but records are still best practice.

Phase-Down Context

The UK is phasing down HFC quotas progressively. R410A (GWP 2,088) is being phased out for new equipment — the EU banned its use in new split systems ≤ 3 kg from 2025. The UK's trajectory broadly mirrors this. R32 and natural refrigerants (R290 propane, R744 CO₂) are the direction of travel. Installers should be confident in R32 handling now and aware that R290-charged small splits are entering the market.

Electrical Requirements

Supply and Isolation

Domestic split systems (2–7 kW cooling) typically draw 5–13 A single phase. The supply circuit should be:

• Protected by an MCB or RCBO rated to the equipment's running current with appropriate diversity
• Isolated by a dedicated local isolator adjacent to the outdoor unit — either a 20 A or 32 A double-pole isolator to BS EN 60947-3, lockable in the off position (mandatory for service access)
• Wired in 2.5 mm² T&E minimum, or as specified by manufacturer

Most manufacturers require a dedicated circuit rather than connection to a ring final; confirm with the equipment data sheet. Some smaller units (≤ 2.5 kW, max 10 A) permit connection via a fused spur, but this is increasingly uncommon.

Part P and Notifiability

A new or extended circuit supplying AC equipment is notifiable under Part P of the Building Regulations. Options:

• Use a Competent Person registered with NAPIT, NICEIC, Stroma, or similar — they self-certify
• Notify the local authority building control department before work (or use the Building Regulations fee route)

The connection of the AC unit itself (control wiring, line connections at the indoor unit) is less clear-cut but follows the same notifiability principle as any fixed electrical installation in a dwelling. Best practice is to have a Part P registered electrician sign off the supply circuit and verify the final connection.

Earthing and Bonding

The outdoor unit must be earthed via the supply cable earth conductor. If the outdoor unit is on a metallic bracket, the bracket itself should be bonded. Check that the TN-C-S or TN-S earthing arrangement at the consumer unit is sound before adding load — an undersized or deteriorating main earthing conductor (MEC) is a latent risk exposed by adding new circuits.

Refrigerant Pipe Runs

Copper refrigerant pipe sets come pre-charged or uncharged. Pre-charged (flared and capped) sets are suitable for short runs ≤ 10 m on specific models; most installs use uncharged sets and require the contractor to pressure-test and vacuum-down before releasing refrigerant from the outdoor unit pre-charge.

Pipe Sizing

Refrigerant pipe sizes are specified by the equipment manufacturer. Typical single split sizes:

• Liquid line: 6.35 mm (¼") OD
• Suction/gas line: 9.52 mm (⅜") to 12.7 mm (½") OD depending on capacity

Never upsize or downsize from manufacturer specification — pipe velocity, oil return, and system efficiency are all affected.

Insulation

Both lines must be insulated. The suction line (carrying cold gas) is the higher priority — inadequate insulation causes condensation, wetting of walls, and reduced efficiency. Use closed-cell elastomeric foam (Armaflex or equivalent) rated for refrigeration duty. Minimum 9 mm wall thickness for liquid line; 13 mm for suction line in typical UK ambient conditions. Outdoor sections need UV-stable jacketing or armoured foam.

Pipe Routing

Route pipes through the wall via a sleeved penetration, pitched slightly towards the outdoor unit on the suction line to ensure oil return. Seal the penetration with fire-rated mastic if passing through compartment walls (Part B). The drain from the indoor unit must gravity-fall to a suitable discharge point — a condensate drain pump is required if gravity drainage is not achievable.

Commissioning

1. Pressure test: Pressurise both lines with dry nitrogen to 1.5× max working pressure (manufacturer specified, typically 40–45 bar for R32 systems). Hold for minimum 60 minutes.
2. Evacuation: Draw vacuum to ≤ 200 microns (0.2 mbar). Hold and verify no rise (indicates residual moisture or leak).
3. Refrigerant release: Open service valves on the outdoor unit to release pre-charge. Record gas type and quantity in the equipment log.
4. Electrical power-on: Run the system in cooling mode, check superheat and subcooling against manufacturer targets, and verify condensate drainage.
5. Hand-over: Demonstrate operation to end user, provide installation record and F-Gas log, and register product for warranty where applicable.

Common Faults and Call-Back Prevention

• E1/F1 communication error: Usually a wiring fault on the 2/3-core control cable between indoor and outdoor units. Check polarity, connections at both units, and continuity. Shielded cable or avoidance of parallel HV runs reduces induced faults.
• Condensate overflow: Blocked condensate tray or drain. Check drain slope; fit condensate pump if gravity inadequate. Clean filter monthly in high-use environments.
• Insufficient cooling: Check refrigerant charge — low charge causes poor performance and risks compressor damage. Check filter is clean; check that doors/windows are closed during cooling mode.
• Outdoor unit noise: Vibration from loose fixings, incorrect fan blade balance, or debris ingress. Check all fixings and clean outdoor coil annually.
• Icing on indoor unit: Usually low refrigerant charge or insufficient airflow. Check filter; if charge is suspect, recover, weigh, and recharge to manufacturer spec.

Permitted Development and Planning

In England, wall-mounted domestic AC outdoor units are generally permitted development (Class A of Part 14, Schedule 2, GDPO) if:

• Volume does not exceed 0.6 m³
• Not on a wall or roof facing a highway
• Not within 1 m of the property boundary
• Not in a conservation area or on a listed building (prior approval required)

Scotland, Wales, and Northern Ireland have separate permitted development regimes — check local planning guidance. Always advise customers to check before installation commences.

Maintenance Recommendations

• Monthly: Clean indoor unit filter; check condensate tray
• Annually: Clean outdoor coil fins; check refrigerant charge; inspect pipe insulation; clean condensate pump (if fitted); check all electrical connections
• Every 2–3 years: Full service by F-Gas certificated engineer; leak check if system is approaching 3 kg CO₂ eq threshold

Specifying the Right System

For a single living room or bedroom (20–30 m² UK room, moderate glazing):

• 2.5–3.5 kW cooling capacity
• R32 inverter split, A++ or better
• SCOP ≥ 4.0 if used for heating
• Sub-50 dB(A) outdoor unit
• Dedicated 16 A RCBO-protected circuit

For whole-home cooling in a 3–4 bed property:

• Multi-split with 10–14 kW outdoor unit
• 4–5 indoor units (mix of capacities per room load)
• Single 32 A supply, dedicated RCBO
• Coordinate installation with other trades — pipe and cable runs plan before plastering
