Thermostatic radiator valves — TRVs — are on every modern domestic heating job. Whether you are fitting a new system, replacing failed valves, or upgrading a property to meet current efficiency expectations, understanding TRV types, sizing, and installation is essential. This guide covers how TRVs work, the difference between straight, angled, and corner valves, how to specify the right head finish, and when to use a lockshield. All products mentioned are available for same-day collection from APM Electricals in Acton, West London.

How a TRV Works

A TRV is a self-regulating valve fitted to the flow connection of a radiator. It contains a wax or liquid-filled sensor element that expands and contracts with temperature changes in the room. As the room reaches the set temperature, the sensor expands, pushing a pin that progressively closes the valve and reduces hot water flow into the radiator. When the room cools, the sensor contracts, the pin lifts, and flow resumes.

The numbered dial on the valve head (typically 1–5 or with a frost symbol) corresponds to room temperature settings — not boiler temperature. Most manufacturers calibrate these at approximately 1 = 10°C, 3 = 20°C (comfortable room temperature for most occupants), 5 = 26°C. Setting 3 or 4 is right for most living spaces; bathrooms and bedrooms often suit 2–3.

TRVs do not replace a room thermostat and do not control the boiler. They regulate individual radiators within a system that is already calling for heat. On any system with a programmer and room thermostat, TRVs provide room-by-room temperature control that reduces energy use by preventing rooms from overheating.

Straight, Angled, and Corner: Which Body Do You Need?

TRV bodies come in three configurations, determined by how the pipework connects to the radiator:

Straight (inline): The flow pipe runs horizontally along the skirting and connects straight into the valve, which connects straight into the radiator. Used where the pipe runs in line with the radiator inlet. Tidy installation, often seen on modern panel radiators with bottom-entry connections.

Angled (90°): The most common configuration in UK domestic installations. The pipe comes up from the floor (or out of the wall low down) and turns 90° to connect into the radiator. An angled valve handles this direction change within the valve body itself. If you are doing like-for-like replacements on most UK homes built since the 1980s, angled valves are what you need.

Corner: Used where the pipe enters from behind the radiator or at a tight angle. The corner body allows a connection that neither straight nor angled can accommodate cleanly. Less common but essential on certain installations, particularly on period properties or where pipework runs in unusual positions.

White Head or Chrome Head: Matching the Finish

TRV heads are available in white and chrome (and less commonly, brushed nickel or black on premium radiator ranges). White heads are the standard for most domestic radiators and most customers will not have a preference either way. Chrome heads are specified in bathrooms, on towel rails, or anywhere the customer wants a more contemporary finish that matches chrome fittings.

The head and body are often sold separately or as matched sets. The EDEN 15mm Straight TRV with White Head and EDEN Angled TRV with Chrome Head are typical examples — same valve body performance, different head aesthetic. The EDEN range from Embrass Peerless is a well-specified mid-range TRV with a smooth action and clear temperature markings.

TRV with Lockshield Sets: The Standard Specification

Every radiator needs two valves — the TRV on the flow side and a lockshield valve on the return side. The lockshield is a fixed-resistance valve that is set during system commissioning to balance the flow across all radiators. Once balanced, it is covered with a cap and not adjusted again in normal use.

Buying TRV and lockshield as a matched set ensures consistent body size, finish, and nut sizing across the radiator. The Taurus Angled TRV with Lockshield is a popular trade choice — a complete pair in white-chrome finish, 15mm x 1/2" connection, suitable for standard domestic panel radiators. Sold as a set, which simplifies ordering and ensures matching.

TRV Sizing: 15mm is the Standard

In UK domestic systems, the standard TRV connection size is 15mm compression (to the pipework) and 1/2" BSP (to the radiator). This covers the vast majority of panel radiators installed since the 1980s. You will occasionally encounter 10mm pipework on older or smaller domestic systems, but 15mm x 1/2" BSP is what you need for standard specification work.

The radiator connection nut size is either 1/2" or 3/4" BSP — check the existing valve or radiator before ordering, as this affects which adaptor or valve tail you need. Most modern panel radiators use a 1/2" connection on both flow and return. Some older or continental-style radiators use 3/4".

When to Replace a TRV

TRVs have a finite lifespan. Common failure modes include:

• Stuck open — the radiator stays hot regardless of the room temperature and dial setting. The wax element has failed or the pin is jammed open. The room overheats. Replace the valve head first (many TRV heads are interchangeable) before replacing the full valve body.
• Stuck closed — the radiator stays cold even with the valve wound fully open. Pin seized in the closed position. Try tapping the pin gently with the head removed — if it frees up, the problem may be temporary. If not, replace the valve body.
• Weeping around the packing gland — water seeping from the spindle area. The gland nut may be undertightened (try a quarter-turn with a spanner) or the packing has failed. If retightening does not stop the leak, replace the valve.

On radiator valve replacement, the system needs to be drained down or the radiator isolated. Fit isolation valves on both sides of the radiator if they are not already present — it saves significant time on all future work.

Bleeding Radiators

While you are on a heating job, it is worth checking for air in the system — particularly after any work that has introduced air into the circuit. The HomeGuard EasyBleed Radiator Bleed Valve replaces the standard manual bleed valve with a push-fit mechanism that speeds up the process on large systems or properties with multiple radiators. Connect a hose to the valve, push, and the air exhausts without mess.

Pick It Up Today in Acton

We stock TRVs, lockshields, and radiator valves in straight, angled, and corner configurations in white and chrome finishes at our Acton trade counter. Browse the radiator valves range and central heating products online, or call 020 8702 8080 to check availability before you come in.
